Product Model

MU3E130M (EGYYO)-NIR

Image Sensor

E2V EV76C661ABT

Color

Mono

Read out mode

Progressive scanning

Shutter Type

Global Shutter

Effective Pixel

1.3MP

Sensor Size

1/1.8”

Pixel size

5.3µm*5.3µm

Maximum Resolution

1280*1024

Frame Rate

60fps

Data Interface

USB3.0 Micro B interface

Power Supply

USB3.0 interface power supply, 250mA @ 5 V

I/O

2 circuit optical coupling isolation, 1 circuit external trigger input, 1 circuit flash output

Image Buffer

FPGA +256Mb frame buffer memory

Basic Function

Image preview, image acquisition, and video recording

Programmable Control

Preview FOV ROI, acquisition FOV ROI, SKIP/Binning mode, contrast, brightness, saturation, Gamma value, Gain, exposure, noise removal, focus assessment, custom serial number (0~255), white balance, LUT lookup table, CCM color correction

White Balance

Automatic / manual control

Exposure

Automatic / manual control

Image Format

Support for RAW 8, MONO 8, BAYER24, BAYER32 image preview acquisition, Jpeg, Bmp, Tiff image format saving

System Support

Support Windows XP/7/10 32bit & 64bit system, Linux X86/ARM system, Android system

SDK

Support C + +, C # development demo. Support OPENCV, LABVIEW, HALCON, MIL, Python and other third-party machine vision software development

Lens interface

C -mount (CS and M12 mount are optional)

Working Temperature

0°C to 60°C

Storage Temperature

– 30°C to 70°C

Camera Size

29mm*29mm*30mm (W*H*L)

Accessories

3m USB cable with fix screws, 6-pin Hirose GPIO connector, 1 CD with software and SDK.
