BS-6023BD Trinocular Metallurgical Microscope
BS-6023BD Trinocular Metallurgical Microscope
BS-6023BD Trinocular Metallurgical Microscope
BS-6023BD Trinocular Metallurgical Microscope
BS-6023BD Trinocular Metallurgical Microscope
BS-6023BD Trinocular Metallurgical Microscope

BS-6023BD Trinocular Metallurgical Microscope

Introduction

BS-6023BD metallurgical microscopes are high level professional microscopes which are specially designed for metallurgical analysis. These microscopes can be used for bright field, dark field, polarizing and DIC observation. With compact structure, excellent optical system and abundant outfit, they can be your best support in research and daily work. The structure is convenient for large-size and thick specimens.

Details

Model:BS-6023BD
Magnification:50×-1000×
Eyepiece:EW10×
Objective:5×,10×,20×,50×,100×
Nosepiece:Quintuple
Illumination:Halogen Light
Viewing Head:Trinocular
Focusing:Coaxial Coarse
Share

Overview

Packaging & Delivery

Packaging Details:Strong Carton with Polyfoam Protection

Port:Beijing

Lead Time:Within 1-2 Weeks after Receiving Payment

Introduction

BS-6023BD metallurgical microscopes are high level professional microscopes which are specially designed for metallurgical analysis. These microscopes can be used for bright field, dark field, polarizing and DIC observation. With compact structure, excellent optical system and abundant outfit, they can be your best support in research and daily work. The structure is convenient for large-size and thick specimens.

Features

  1. Can be used for bright field, dark field, simple polarization and DIC observation, compact and flexible.
  2. Halogen light, 150W cold light source, 40W LED cold light source are available, the brightness is sufficient to meet a variety of observation requirements.
  3. Large base, high column. Convenient for large-size LCD panel, PCB board and thicker or larger sample observation.
  4. Ideal instrument for metallurgical analysis, industry inspection and science research.

Application

BS-6023BD are widely used in institutes and laboratories to observe and identify the structure of various metal and alloy, they also can be used in electronics, chemical and instrumentation industry, observe the opaque material and transparent material, such as metal, ceramics, integrated circuits, electronic chips, printed circuit boards, LCD panels, film, powder, toner, wire, fibers, plated coatings, other non-metallic materials and so on.

Specification

Item

Specification

BS-6023B

BS-6023BD

Optical System

Infinite optical system

Viewing Head

Siedentopf trinocular viewing head, inclined at 30°, rotate360°, interpupillary distance 48mm-75mm, light distribution: 80:20

Eyepiece

Extra wide field eyepiece EW10×/22mm, eyepiece tube Φ30mm

Infinite Plan Achromatic Objective

5×/ 0.12/∞/ – (BF)       WD 15.5mm



10×/ 0.25/∞/ – (BF)      WD 10.0mm



20×/ 0.4/∞/ 0 (BF)       WD 5.8mm



50×/ 0.75/∞/ 0 (BF)      WD 0.32mm



100×/ 0.8/∞/ 0 (BF)      WD 2.0mm



5×/ 0.12/∞/ – (BF&DF)    WD 12.0mm



10×/ 0.25/∞/ – (BF&DF)   WD 10.0mm



20×/ 0.4/∞/ 0 (BF&DF)    WD 4.3mm



50×/ 0.75/∞/ 0 (BF&DF)   WD 0.32mm



100×/ 0.8/∞/ 0 (BF&DF)   WD 2.0mm



DIC

DIC Attachment 20×, 100×

Reflected Light

24V/100W Halogen light, Brightness adjustable

150W Cold Light, Brightness adjustable

40W LED illumination, Brightness adjustable

Polarizer and analyzer

Blue, Green, Yellow and Frosted filter

Focusing

Coaxial coarse and fine adjustment, Fine Division 0.001mm, Moving Range 32mm

Nosepiece

Backward quintuple nosepiece

Stand

Size of the base: 396×276mm×22mm, the height of the column 300mm, diameter 30mm

Accessories

Specimen Presser

Photo Attachment for Nikon or Canon DSLR camera

Video Attachment, C-Mount 1×, 0.5×

Note: ●Standard Outfit, ○Optional
