BS-7020 Inverted Fluorescent Biological Microscope
BS-7020 Inverted Fluorescent Biological Microscope
BS-7020 Inverted Fluorescent Biological Microscope
BS-7020 Inverted Fluorescent Biological Microscope
BS-7020 Inverted Fluorescent Biological Microscope
BS-7020 Inverted Fluorescent Biological Microscope
BS-7020 Inverted Fluorescent Biological Microscope
BS-7020 Inverted Fluorescent Biological Microscope

BS-7020 Inverted Fluorescent Biological Microscope

Introduction

BS-7020 inverted fluorescence microscope uses mercury lamp as the light source, objects which are radiated then fluoresce, and then the shape of an object and its location can be observed under the microscope. The Microscope is specifically designed for the observation of cell culture. Excellent high resolution objectives provide high quality fluorescent images. Infinite Optical System gives excellent Optical performance. This microscope can be your best assistant in laboratory research.

Details

Model:BS-7020
Magnification:40×-400×
Eyepiece:WF10×
Objective:4×, 10×, 20×, 40×
Condenser:NA 0.3
Illumination:Halogen Lamp
Viewing Head:Trinocular
Reflected Light Source:Blue,Green
Share

Overview

Packaging & Delivery

Packaging Details:Strong Carton with Polyfoam Protection

Port:Beijing

Lead Time:Within 1-2 Weeks after Receiving Payment

Introduction

BS-7020 inverted fluorescence microscope uses mercury lamp as the light source, objects which are radiated then fluoresce, and then the shape of an object and its location can be observed under the microscope. The Microscope is specifically designed for the observation of cell culture. Excellent high resolution objectives provide high quality fluorescent images. Infinite Optical System gives excellent Optical performance. This microscope can be your best assistant in laboratory research.

Features

  1. Perfect image with infinite optical system.
  2. High resolution fluorescent objectives are optional for excellent fluorescent images.
  3. Advanced and precision lamp housing reduces the light leak.
  4. Reliable power supply with digital display and timer.
  5. Innovative structure and sharp Image is perfect for viewing cell tissue.

Application

BS-7020 Inverted Fluorescent Biological Microscope is specifically designed for the observation of cell culture. It is widely used in universities, hospitals and life science labs for disease examination, immune diagnosis and scientific research.

Specification

Item

Specification

BS-7020

Optical System

Infinite Optical System

Viewing Head

Seidentopf Trinocular Viewing Head, Inclined at 45°, 360° Rotatable, Interpupillary Distance 48-75mm

Eyepiece

Wide Field Eyepiece WF10×/ 20mm, Eyepiece Tube Diameter 30mm

Wide Field Eyepiece WF15×/ 16mm

Wide Field Eyepiece WF20×/ 12mm

Objective

LWD(Long Working Distance) Infinite Plan Achromatic Objective 4×/0.1, W.D.= 22mm

LWD(Long Working Distance) Infinite Plan Achromatic Phase Objective

10×/ 0.25,   W.D.= 6mm

20×/ 0.4,    W.D.= 3.1mm

40×/ 0.55,   W.D.= 2.2mm

High Level Phase Contrast Objective

10×/ 0.25,   W.D.= 6mm

20×/ 0.4,    W.D.= 3.1mm

40×/ 0.55,   W.D.= 2.2mm

Lamp House Adjustment Objective

Nosepiece

Backward Quintuple Nosepiece

Condenser

ELWD(Extra Long Working Distance) Condenser NA 0.3, LWD 72mm (Without Condenser 150mm)

Telescope

Centering Telescope (Φ30mm)

Phase Annular

10×, 20×, 40× Phase Annular Plate(Center Adjustable)

Stage

Plain Stage 230×170mm

Glass Insert Plate

Attachable Mechanical Stage, X,Y Coaxial Control, Moving Rang 80mm×120mm

Auxiliary Stages 70mm×180mm

Terasaki Holder

Petri Dish Holder Φ38mm

Petri Dish Holder Φ54mm

Focusing

Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Moving Range up 4.5mm, down 4.5mm

Transmitted Illumination

Halogen Lamp 6V/30W, Brightness Adjustable

LED lamp 5W, Brightness Adjustable

Reflected Light Source



Excitation

Dichroic Mirror

Barrier Filter



Blue excitation

BP460~490

DM500

BA520

Green excitation

BP480~550

DM570

BA590

Ultraviolet excitation

BP330~385

DM400

BA420

Violet excitation

BP400~410

DM455

BA455

Red Excitation

BP620~650

DM660

BA670-750

Lamp

100W HBO Ultra Hi-voltage Spherical Mercury Lamp

Protection barrier

Barrier to Resist the Ultraviolet Light

Power Supplier

Power Supplier NFP-1, 220V/ 110V interchangeable, Digital Display

Immersion Oil

Fluorescent Free Oil

Centering Target



Filter

Blue, Green and Ground Glass, Diameter 45mm

Accessories

Photo Adapter (Used to connect Nikon or Canon DSLR camera to the microscope)

0.5× C-mount (Used to directly connect a C-mount digital camera to the microscope)

Modulation Contrast

Package

2 cartons/set, 36*61*62cm, 18kg; 38*45*26cm, 6kg

Note: ● Standard Outfit, ○ Optional
