BS-2070FB(LED) Fluorescent Biological Microscope
BS-2070FB(LED) Fluorescent Biological Microscope
BS-2070FB(LED) Fluorescent Biological Microscope
BS-2070FB(LED) Fluorescent Biological Microscope
BS-2070FB(LED) Fluorescent Biological Microscope
BS-2070FB(LED) Fluorescent Biological Microscope

BS-2070FB(LED) Fluorescent Biological Microscope

Introduction

BS-2070F(LED) Series LED fluorescence microscopes are newly developed microscopes, the microscopes use LED as the fluorescent light source, the life span of the LED lamp is much longer than mercury lamp, the performance is also better.

Details

Model:BS-2070FB(LED)
Magnification:40x-1000x
Eyepiece:WF10x
Objective:4×, 10×, 40×, 100×
Illumination:S-LED
Stage:230×150mm
Viewing Head:Binocular
Condenser:NA1.25
Share

Overview

Packaging & Delivery

Packaging Details:Strong Carton with Polyfoam Protection

Port:Beijing

Lead Time:Within 2-4 Weeks after Receiving Payment

Introduction

BS-2070F(LED) Series LED fluorescence microscopes are newly developed microscopes, the microscopes use LED as the fluorescent light source, the life span of the LED lamp is much longer than mercury lamp, the performance is also better.

Features

  1. Excellent fluorescent image with infinite optical system.
  2. LED illumination with 50,000 hours life span.
  3. No need for cooling system and protection device due to LED cold light source.
  4. 465-476nm excited wavelength with high SNR.
  5. Convenient to use, no need warm-up.
  6. More fluorescent filters are available for different applications.

Application

BS-2070F(LED) LED Fluorescence microscopes are used to study the absorbing, transportation, chemicals distribution and positioning in cells. They can be used in disease examination, immune diagnosis and life science areas.

Specification

Item

Specification

BS-2070

FB(LED)

BS-2070

FT(LED)

Optical System

Infinite Optical System

Viewing Head

Seidentopf Binocular Viewing Head, Inclined at 30°, 360° Rotatable, Interpupillary 48-75mm



Seidentopf Trinocular Viewing Head, Inclined at 30°, 360° Rotatable, Interpupillary 48-75mm



Eyepiece

WF10×/20mm

WF15×/16mm

Objective

Infinite Plan Achromatic Objective 4×, 10×, 40×, 100×

Infinite Plan Achromatic Objective 20×, 60×

Nosepiece

Backward Quadruple Nosepiece

Backward Quintuple Nosepiece

Focusing

Coaxial Coarse & Fine Adjustment, Fine Division 0.002mm, Coarse Stroke 37.7mm per Rotation, Fine Stroke 0.2mm per Rotation, Moving Range 22mm

Stage

Rectangular 230×150mm, Cross Travel 78×54mm, Using Low-positioned X/ Y Coaxial Control Knob, Can Hold Two Sides

Condenser

Abbe Condenser NA1.25 with Aperture Diaphragm

Illumination

12V/20W Halogen Lamp, Brightness Adjustable

1W S-LED illumination, brightness adjustable

Optional Accessories

Photo attachment, Video attachment, Polarization set, Phase contrast kit, Kohler Illumination

Reflected Light Source



Excitation

Dichroic Mirror

Barrier Filter





Blue excitation

BP460~490

DM505

BA515

Green excitation

BP510~550

DM570

BA590

Fluorescent Lamp

3W LED Lamp(465-476nm)

3W LED Lamp(525-530nm)

Immersion Oil

Fluorescent Free Oil

Package

2cartons/set, 38cm*26cm*51cm, 9kg; 44cm*38cm*17cm, 3kg

Note: ●Standard Outfit, ○Optional
