BUC4C-200C C-mount USB2.0 CCD Microscope Camera (ICX274AQ Sensor, 2.0MP)
BUC4C-200C C-mount USB2.0 CCD Microscope Camera (ICX274AQ Sensor, 2.0MP)
BUC4C-200C C-mount USB2.0 CCD Microscope Camera (ICX274AQ Sensor, 2.0MP)
BUC4C-200C C-mount USB2.0 CCD Microscope Camera (ICX274AQ Sensor, 2.0MP)
BUC4C-200C C-mount USB2.0 CCD Microscope Camera (ICX274AQ Sensor, 2.0MP)
BUC4C-200C C-mount USB2.0 CCD Microscope Camera (ICX274AQ Sensor, 2.0MP)
BUC4C-200C C-mount USB2.0 CCD Microscope Camera (ICX274AQ Sensor, 2.0MP)
BUC4C-200C C-mount USB2.0 CCD Microscope Camera (ICX274AQ Sensor, 2.0MP)
BUC4C-200C C-mount USB2.0 CCD Microscope Camera (ICX274AQ Sensor, 2.0MP)
BUC4C-200C C-mount USB2.0 CCD Microscope Camera (ICX274AQ Sensor, 2.0MP)

BUC4C-200C C-mount USB2.0 CCD Microscope Camera (ICX274AQ Sensor, 2.0MP)

Introduction

BUC4C-200C(With ICX274AQ(C) Sensor) CCD cameras are ultra-high performance Super HAD CCD camera. The cameras adopt CCD sensor as the image capture device; The Super HAD CCD is a version of high performance CCD HAD (Hole-Accumulation Diode) sensor with sharply improved sensitivity by the incorporation of a new semiconductor technology developed. USB2.0 is used as the data transfer interface.

Details

Model:BUC4C-200C
Sensor:2.0M/ICX274AQ(C)
Sensor Size(mm):1/1.8“ (7.04x5.28)
Pixel Size(μm):4.40x4.40
FPS:10@1600x1200
Binning:1x1
Exposure:0.135ms~60s
USB Port:USB2.0 High-speed Port
Share

Overview

Packaging & Delivery

Packaging Details:Strong Carton with Polyfoam Protection

Port:Beijing

Lead Time:Within 1-2 Weeks after Receiving Payment

Introduction

BUC4C-200C(With ICX274AQ(C) Sensor) CCD cameras are ultra-high performance Super HAD CCD camera. The cameras adopt CCD sensor as the image capture device; The Super HAD CCD is a version of high performance CCD HAD (Hole-Accumulation Diode) sensor with sharply improved sensitivity by the incorporation of a new semiconductor technology developed. USB2.0 is used as the data transfer interface.

BUC4C series CCD cameras come with advanced video & image processing application ImageView; Providing Windows/Linux/OSX multiple platform SDK; Native C/C++, C#/VB.NET, DirectShow, Twain Control API;

The BUC4C series CCD cameras can be widely used in bright field, dark field, fluorescent light environment for microscope image capture and analysis.

Features

  1. Standard C-Mount camera with CCD 0.8~5.2M sensor;
  2. USB2.0 interface ensuring high speed data transmission;
  3. Ultra-Fine color engine with perfect color reproduction capability;
  4. With advanced video & image processing application ImageView;
  5. Providing Windows/Linux/Mac OS multiple platforms SDK;
  6. Native C/C++, C#/VB.NET, DirectShow, Twain Control API.

BUC4C Datasheet

Order Code

Sensor & Size(mm)

Pixel Size(μm)

G Sensitivity

Dark Signal

FPS/Resolution

Binning

Exposure

BUC4C-520C

5.2M/ICX655AQ(C)
2/3“ (8.44×7.07)

3.45×3.45

420mv with 1/30s

4mv with 1/30s

4.3@2448×2050
10.5@960×720

1×1

0.22ms~60s

BUC4C-510C

5.1M/ICX452AQ(C)
1/1.8“ (7.19×5.39)

2.775×2.775

260mv with 1/30s

16mv with 1/30s

4@2592×1944
35@560×420

1×1, 2×2

0.212ms~77ms

BUC4C-500C

5.0M/ICX282AQ(C)
2/3“ (8.70×6.53)

3.40×3.40

280mv with 1/30s

16mv with 1/30s

4.5@2560×1920
9@1280×960

1×1, 2×2

0.203ms~60s

BUC4C-200C

2.0M/ICX274AQ(C)
1/1.8“ (7.04×5.28)

4.40×4.40

420mv with 1/30s

8mv with 1/30s

10@1600×1200

1×1

0.135ms~60s

BUC4C-140BC

1.4M/ICX205AK(C)
1/2“ (6.32×4.76)

4.65×4.65

400mv with 1/30s

16mv with 1/30s

15@1360×1024

1×1

0.127ms~60s

BUC4C-140M

1.4M/ICX205AL(M)
1/2“ (6.32×4.76)

4.65×4.65

450mv with 1/30s

16mv with 1/30s

15@1360×1024

1×1

0.127ms~60s

C:Color; M:Monochrome;



Other Specification for BUC4C

Spectral Range

380-650nm (with IR-cut Filter)

White Balance

ROI White Balance/ Manual Temp Tint Adjustment/NA for Monochromatic Sensor

Color Technique

Ultra-FineTM Color Engine/NA for Monochromatic Sensor

Capture/Control API

Native C/C++, C#/VB.NET, DirectShow, Twain and Labview

Recording System

Still Picture and Movie

Cooling System*

Natural

Operating Environment

Operating Temperature(in Centigrade)

-10~ 50

Storage Temperature(in Centigrade)

-20~ 60

Operating Humidity

30~80%RH

Storage Humidity

10~60%RH

Power Supply

DC 5V over PC USB Port

Software Environment

Operating System

Microsoft® Windows® XP / Vista / 7 / 8 /10 (32 & 64 bit)

OSx(Mac OS X)

Linux

PC Requirements

CPU: Equal to Intel Core2 2.8GHz or Higher

Memory:2GB or More

USB Port:USB2.0 High-speed Port

Display:17” or Larger

CD-ROM

Dimension of BUC4C

The BUC4C body, made from tough, zinc alloy, ensures a heavy duty, workhorse solution. The camera is designed with a high quality IR-CUT to protect the camera sensor. No moving parts included. These measures ensure a rugged, robust solution with an increased lifespan when compared to other industrial camera solutions.

Packing Information of BUC4C

Standard Camera Packing List

A

Carton L:52cm W:32cm H:33cm (20pcs, 12~17Kg/ carton), not shown in the photo

B

Gift box L:15cm W:15cm H:10cm (0.67~0.8Kg/ box)

C

BUC4C series camera

D

High-speed USB2.0 A male to B male gold-plated connectors cable /2.0m

E

CD (Driver & utilities software, Ø12cm)

Optional Accessory

F

Adjustable lens adapter

 C-mount to Dia.23.2mm eyepiece tube
 (Please choose 1 of them for your microscope)

 C-mount to Dia.31.75mm eyepiece tube
 (Please choose 1 of them for your telescope)

G

Fixed lens adapter

 C-mount to Dia.23.2mm eyepiece tube
 (Please choose 1 of them for your microscope)

 C-mount to Dia.31.75mm eyepiece tube
 (Please choose 1 of them for your telescope)

Note: For F and G optional items, please specify your camera type(C-mount, microscope camera or telescope camera) , engineer will help you to determine the right microscope or telescope camera adapter for your application;

H

108015(Dia.23.2mm to 30.0mm Ring)/Adaptor rings for 30mm eyepiece tube

I

108016(Dia.23.2mm to 30.5mm Ring)/ Adaptor rings for 30.5mm eyepiece tube

J

108017(Dia.23.2mm to 31.75mm Ring)/ Adaptor rings for 31.75mm eyepiece tube

K

Calibration kit

106011/TS-M1(X=0.01mm/100Div.);
106012/TS-M2(X,Y=0.01mm/100Div.);
106013/TS-M7(X=0.01mm/100Div., 0.10mm/100Div.)
